For use with all solenoid motors (e.g. PL-10 and Pl-11). Connect this unit to the 16v ac supply on your transformer. The capacitor stores up power and discharges a 'kick' to ensure turnout blades 'snap over' every time.

Makes wiring the PL-10 series of Motors quick and easy. Just a simple push fit onto the motor terminals; the other ends are tinned and ready for the PL-39 Terminal Block, PL-50 Switch Module Unit, or PL-31 Push on Terminal Connectors.

Closed type, rated 16v 2amps (continuous) or 2.5amps (momentary). Use this microswitch with the PL-19 Microswitch Housing for polarity switching the SL-E790BH 0 Gauge Double Slip.

Open type, as used on the PL-15 Twin Microswitch. Rated 16v 2amps (continuous) or 2.5amps (momentary).

Push on Terminal Connectors and shrouds. These connectors make modification and fault finding so much easier than soldered wiring. Use them to connect the PL-38 Wire to PL-26 Passing Contact Switches, PL-22 On/Off Switches, PL-23 On/On Switches, and PL-34 Wiring Looms to PL-26 Passing Contact Switches. They can also be used when connecting wires to other items, for example, PL-13 Accessory Switches, PL-15 Twin Microswitches, PL-10 Turnout Motors, and PL-32 and 33 Microswitches.

These can be used directly from terminals on the Smartswitch (TM) Control Board (PLS-120) and Smartfrog (PLS-130) to show route selection. They can also be powered via a 12v DC supply if the PL-29 Resistors are included in the circuit.

Resistors for use with the PL-30 Red and Green LED's.

Use these when creating a diagrammatic control panel to clip fit PL-26 Passing Contact Switches, PL-22 On/Off Switches and PL-23 On/On Switches in the required place.

Houses 6 PL-26 Passing Contact Switches, PL-22 On/Off Switches or PL-23 On/On Switches.

Provides the short burst of current required to operate the PL-11 and PL-10 series of Turnout Motors. The PL-31 Connectors are ideal for attaching the PL-34 Wiring Looms or PL-38 wire to these switches without soldering; the included Shrouds prevent current 'shorting out' between the terminals.

Provides the short burst of current required to operate the PL-11 and PL-10 series of Turnout Motors. The PL-31 Connectors are ideal for attaching the PL-34 Wiring Looms or PL-38 wire to these switches without soldering; the included Shrouds prevent current 'shorting out' between the terminals.

Provides the short burst of current required to operate the PL-11 and PL-10 series of Turnout Motors. The PL-31 Connectors are ideal for attaching the PL-34 Wiring Looms or PL-38 wire to these switches without soldering; the included Shrouds prevent current 'shorting out' between the terminals.
